Theatrixx Technologies

Theatrixx xVision DUAL 4K Fibre to SDI Converter - MultiMode opticalCON DUO to 12G-SDI

SKU: XVV2FIBER2SDI-12GM2
Theatrixx xVision DUAL 4K Fibre to SDI Converter - MultiMode opticalCON DUO to 12G-SDI
Theatrixx xVision DUAL 4K Fibre to SDI Converter - MultiMode opticalCON DUO to 12G-SDI
Theatrixx xVision DUAL 4K Fibre to SDI Converter - MultiMode opticalCON DUO to 12G-SDI
Theatrixx xVision DUAL 4K Fibre to SDI Converter - MultiMode opticalCON DUO to 12G-SDI
Theatrixx xVision DUAL 4K Fibre to SDI Converter - MultiMode opticalCON DUO to 12G-SDI
Theatrixx xVision DUAL 4K Fibre to SDI Converter - MultiMode opticalCON DUO to 12G-SDI
Click to enlarge

    £2,473.50 inc VAT
    £2,061.25 ex VAT

    1 in stock (more available subject to additional lead time)

    Order in 19h 40m 28s for FREE delivery by Tuesday
    Click & collect available Monday ›
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    5 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    Two independent 4K fibre-to-SDI converters in one B-size enclosure. The Theatrixx xVision DUAL Fibre MultiMode to 12G-SDI converter provides two completely independent conversion paths, each taking multi-mode fibre via Neutrik opticalCON DUO and outputting 12G-SDI. For productions running multiple 4K camera returns or parallel video feeds, this halves the box count – and halves the mounting points, power connections, and failure modes in your rig.

    Input
    2x Fibre MM
    opticalCON DUO

    Output
    2x 12G-SDI
    4K capable

    Resolution
    4K UHD
    12G-SDI

    Form Factor
    B-Size
    Dual converter

    Features
    ✓
    Two independent multi-mode fibre to 12G-SDI conversion paths
    ✓
    B-size format – two converters in one enclosure, halving box count
    ✓
    Neutrik opticalCON DUO inputs for rugged fibre termination
    ✓
    Rugged touring enclosure – no exposed PCBs
    ✓
    Single internal power supply for both channels – no external power bricks
    ✓
    Professional locking connectors on all ports
    ✓
    Magnetic mounting system with spring-loaded plunger retention
    ✓
    Ideal for multi-camera 4K productions and parallel video feeds

    Specifications
    Input 2x Multi-mode fibre (opticalCON DUO)
    Output 2x 12G-SDI
    Resolution Up to 4K UHD (12G-SDI)
    Channels 2 independent conversion paths
    Input Connectors 2x Neutrik opticalCON DUO
    Output Connectors 2x BNC (12G-SDI)
    Fibre Type Multi-mode
    Form Factor B-Size Standalone (Dual)
    SKU XVV2FIBER2SDI-12GM2

    More Information

    • Integrated power supply with locking PowerCON Connector. Never rely on a cluster of wall-warts again.
    • Built-in convenience AC outlet to power nearby projector, TV, laptop, small video projector… Power bar to power both the converter and device not required anymore.
    • Magnetic stacking system and non-skid rubber pad for table top application. Saves at least 10 gaffer tape rolls a year.
    • Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adaptor.
    • Rugged, Tour-ready and aesthetic enclosure
    • Plug-n-play operation; No dipswitches, buttons or menus to fumble with : It just works.
    • Clear and ample status LED indicators for quick troubleshooting.
    • Easy on-the-field identification with unique colour and alphabetic coding system.
    • SFP-based video transmission for interoperability with standard SDI over fibre devices.
    • Reclocked and amplified SDI loop thru
    • Proudly designed and assembled in Canada
