ADJ Jolt Panel FXIP Outdoor LED Strobe / Wash Panel

SKU: ADJ1226200074
ADJ Jolt Panel FXIP Outdoor LED Strobe / Wash Panel
ADJ Jolt Panel FXIP Outdoor LED Strobe / Wash Panel
ADJ Jolt Panel FXIP Outdoor LED Strobe / Wash Panel
ADJ Jolt Panel FXIP Outdoor LED Strobe / Wash Panel
ADJ Jolt Panel FXIP Outdoor LED Strobe / Wash Panel
ADJ Jolt Panel FXIP Outdoor LED Strobe / Wash Panel
Click to enlarge

    £784.00 inc VAT
    £653.33 ex VAT

    15 in stock

    Order in 18h 23m 49s for FREE delivery by Tuesday
    Click & collect available Monday ›
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    2 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    The ADJ Jolt Panel FXIP is the IP65-rated outdoor version of the Jolt Panel FX. Forty-eight 5W cool white SMDs at the centre deliver traditional strobing, surrounded by 800 x 0.5W RGB SMDs for colour wash and pixel effects, all in a sealed housing for temporary outdoor use. 6 white and 40 colour zones run independently for chase patterns, with built-in Aria X2 wireless DMX.

    WHITE LEDS
    48 x 5W
    6900-7400K

    RGB LEDS
    800 x 0.5W
    SMD

    BEAM
    73°
    111° field

    RATING
    IP65
    Outdoor use

    Independent zone control

    6 white and 40 RGB zones can be addressed independently for chase patterns, animated effects and pixel work. Built-in Aria X2 wireless allows OTA setup and DMX distribution.

    Features
    ✓48 x 5W cool white SMD strobe (6900-7400K)
    ✓800 x 0.5W RGB SMDs for colour wash and effects
    ✓6 white and 40 RGB independently controllable zones
    ✓Strobe rate 1 to 20Hz
    ✓Refresh rate 900Hz to 25kHz, flicker free
    ✓Aria X2 wireless DMX with OTA updates
    ✓IP65 rated for temporary outdoor or indoor use
    ✓Multi-voltage 100 to 240V AC (208W @ 230V)

    Specifications
    White LEDs 48 x 5W SMD, 6900-7400K
    RGB LEDs 800 x 0.5W SMD (R 620-630nm, G 515-525nm, B 460-470nm)
    Zones 6 white + 40 RGB independent
    Beam / field angle 73 / 111 degrees
    Strobe rate 1 to 20Hz
    Refresh rate 900Hz to 25kHz
    Wireless Aria X2
    IP rating IP65
    Power input 100 to 240V AC, 50/60Hz
    Power consumption 208W @ 230V

    More Information

    LIGHT SOURCE:
    • 800 x 0.5-Watt RGB SMD LEDs + 48 x 5-Watt Cool White SMD LEDs
    • Beam Angle: 73°
    • Field Angle: 111°
    • RGB LED Specs: Red: 620-630nm; Green: 515-530nm; Blue: 460-470nm
    • White LEDs CCT: Typical 7400K (Min. 6900 - Max 8000), 472nm
    • CRI: 69.4
    • 50,000 Hour Average LED Life
    FEATURES:
    • Aria X2 Wireless Management System
    • 40 x RGB LED Zones (126, 141 and 143 ch modes)
    • 6 x Cool White LED Zones (51, 81, 83, 126, 141 and 143 ch modes)
    • 67 Built-In Colour Temperature Presets (2300K-8900K)
    • 25 Built-in RGB LED Program Macros
    • 9 Built-in Cool White LED Program Macros
    • IP65-Rated for temporary outdoor and indoor use
    • Channel for Light Shaping Filters (to Blur Pixel Dots)
    • Built-in Holes to Connect an Omega Bracket (sold separately)
    CONTROL:
    • Control Protocols: DMX, Aria X2 and RDM
    • 10 DMX Channel Modes: 6, 9, 13, 18, 36, 41, 51, 81, 126 and 141 channel modes
    • Dim Modes: 6 Presets (Standard, Stage, TV, Architectural, Theatre & Stage 2)
    • Dim Curves: 4 Presets (Linear, Square Law, Inv Square Law & S Curve)
    • 0-100% Smooth Dimming
    • Strobe, Shutter & Pulse Control
    • Max Strobe Rate: 20Hz; Min Strobe Rate: 1Hz
    • Refresh Rate: 900Hz - 25kHz
    • Display: OLED Display with 4-Button Touch Menu
    CONNECTIONS:
    • Data: IP65-rated Locking 5-pin DMX In/Out
    • Power: IP65 Locking Power In/Out
    ELECTRICAL:
    • Multi-voltage operation: AC100-240V, 50/60Hz (Auto Sensing)
    • Max Power Consumption: 208W @230V
    • Max Power Link: 12pcs @230V
    • Fuse Protected: T5A/250V Glass Fuse (5x20MM)
    DIMENSIONS / WEIGHT:
    • Length: 417mm
    • Width: 280mm
    • Height: 213mm
    • Weight: 9.1 kg
    WHAT'S INCLUDED:
    • 1x IP65 locking power cable
    • Diffusion filter
    OPTIONAL ACCESSORIES:
    • 180mm Omega Bracket Hydro (SKU 9900026435)
    • Jolt Panel FX BLKF
    • Jolt Panel FX 1x60 LF (60x1° Beam Shape filter)
    • Jolt Panel FX 60x1 LF (1x60° Beam Shape filter)
    APPROVALS / RATINGS:
    • IP65

    Manuals & Downloads

    PDFManuals & Instructions: adj_jolt_panel_fxip_-_user_manual_2.pdfPDF
