The Sennheiser GZL RG 8x is a 10-metre low-damping coaxial antenna cable terminated with BNC connectors at both ends, used to connect remote antennas to wireless microphone receivers. With 50 ohm impedance and a frequency range up to 4000 MHz, it is built for production companies, venues and AV professionals running antennas away from the receiver rack for improved RF coverage.
Compatibility
BNC cable for connecting remote antennas to Sennheiser wireless receivers and RF distribution systems. With a frequency range to 4000 MHz it supports the full range of UK wireless microphone and in-ear bands.
Features
✓Low-damping coaxial construction for reduced signal loss over longer runs
✓BNC connectors fitted at both ends
✓50 ohm impedance for matched RF transmission
✓Frequency range up to 4000 MHz
✓Low attenuation of 16.8 dB/100 m at 400 MHz
✓Wide operating temperature range of -40 to 70 °C for indoor and outdoor use
✓Slim 6.8 mm cable diameter for tidy installation
✓10 m length for remote antenna placement
Specifications
| Manufacturer | Sennheiser |
| Model | GZL RG 8x – 10m |
| Article number | 700164 |
| Type | Low-damping coaxial antenna cable |
| Connectors | BNC (both ends) |
| Length | 10 m |
| Impedance | 50 ohm |
| Frequency range | max. 4000 MHz |
| Attenuation @ 400 MHz (20 °C) | 16.8 dB/100 m |
| Cable diameter | 6.8 mm |
| Conductor DC resistance | ≤ 3.2 Ω/100 m |
| Capacitance | 82 pF/m |
| Operating temperature | -40 to 70 °C |
| Weight | 435 g |
