Theatrixx xVision 4K 1:4 12G-SDI Distribution Amplifier Splitter

SKU: XVVSDIDA4T1-12G
Theatrixx xVision 4K 1:4 12G-SDI Distribution Amplifier Splitter
Theatrixx xVision 4K 1:4 12G-SDI Distribution Amplifier Splitter
Theatrixx xVision 4K 1:4 12G-SDI Distribution Amplifier Splitter
Theatrixx xVision 4K 1:4 12G-SDI Distribution Amplifier Splitter
Click to enlarge

    £599.00 inc VAT
    £499.17 ex VAT

    6 in stock (more available subject to additional lead time)

    Order in 19h 40m 57s for FREE delivery by Tuesday
    Click & collect available Monday ›
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    5 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    The Theatrixx xVision 4K 1:4 12G-SDI Distribution Amplifier takes a single 12G-SDI input and distributes it to four re-clocked outputs, supporting resolutions up to 4K/UHD over a single BNC connection. Built in the compact A-size standalone format with internal power supply and locking connectors, it delivers high-bandwidth SDI distribution in a rugged, road-ready package.

    Outputs
    4
    Re-clocked SDI

    Max Data Rate
    12G-SDI
    Up to 4K/UHD

    Form Factor
    A-Size
    Standalone

    Power
    Internal PSU
    No external adaptor

    Features
    ✓
    1 input to 4 re-clocked 12G-SDI outputs
    ✓
    Full 4K/UHD support over single-link 12G-SDI
    ✓
    Backwards compatible with 3G-SDI, HD-SDI, and SD-SDI
    ✓
    Internal power supply – no external adaptor required
    ✓
    Locking power connector for secure mains connection
    ✓
    Compact A-size standalone enclosure – built for touring and install
    ✓
    Automatic input format detection
    ✓
    Compatible with xVision rack frames for multi-unit installations

    Specifications
    SKU XVVSDIDA4T1-12G
    Input 1x 12G-SDI (BNC)
    Outputs 4x 12G-SDI (BNC)
    SDI Standard SD-SDI / HD-SDI / 3G-SDI / 12G-SDI
    Max Resolution 4K / UHD
    Form Factor A-Size Standalone
    Power Internal PSU, locking connector
    Manufacturer Theatrixx

    More Information

    • Integrated power supply with locking PowerCON connector. Never rely on a cluster of wall-warts again.
    • Built-in convenience outlet to power nearby monitor, flat-screen, laptop, video projector or any device up to 10 amps… Power bar to connect both converter and device not required anymore.
    • Magnetic stacking system and non-skid rubber pad. Saves at least 10 gaffer tape rolls a year.
    • Multiple mounting options: C-Clamp, wall-mount adapter, LCD mount adapter and belt adapter.
    • Rugged, Tour-ready and aesthetic enclosure: The sexiest widget in your tool box, that will keep looking good for years to come.
    • Plug-n-play operation; No dipswitches, buttons or menus to fumble with: It just works.
    • Clear and ample status LED indicators for quick troubleshooting.
    • Easy on-the-field identification with unique colour and alphabetic coding system.
    • Locking HDMI port prevents accidental disconnection.
    • Reclocked and amplified SDI loop thru
    • Proudly designed and assembled in Canada.
