The Linea Research 44 M20 Dante is the most powerful amplifier in the 44M Series, now with integrated Dante network audio. Each of the four channels delivers 3,000W at 4 Ohms – all simultaneously – with bridged mode capable of up to 10,000W for the most demanding subwoofer deployments. Dante connectivity enables audio routing over standard Ethernet, streamlining cabling on large-scale touring and festival systems. Combined with 96kHz DSP, LIR linear phase crossovers, and the VX Limiter suite, the M20 Dante is a complete amplification and processing platform.
Channels
4
Independent
Power per Channel
3,000W
@ 4 Ohms
Total Power
12,000W
All channels driven
Bridged Power
10,000W
Per bridged pair
Form Factor
2U
Rack mount
DSP Sample Rate
96kHz
LIR crossovers
Network Audio
Dante
Integrated
Dante Network Audio
Integrated Dante delivers audio over standard Ethernet, enabling flexible signal routing and centralised control across large systems. This is particularly advantageous for touring and festival deployments where rapid setup and reduced cabling are priorities. The analogue-only 44 M20 (ZR1260) is also available.
Features
✓
Integrated Dante for network audio distribution over standard Ethernet
Integrated Dante for network audio distribution over standard Ethernet
✓
12,000W total – all four channels at full rated power simultaneously, no burst ratings
12,000W total – all four channels at full rated power simultaneously, no burst ratings
✓
Bridged mode capable of up to 10,000W for high-demand subwoofer applications
Bridged mode capable of up to 10,000W for high-demand subwoofer applications
✓
Independently verified 7-10% efficiency advantage over competing amplifiers
Independently verified 7-10% efficiency advantage over competing amplifiers
✓
96kHz DSP engine with LIR linear phase crossover filters – lower latency than FIR
96kHz DSP engine with LIR linear phase crossover filters – lower latency than FIR
✓
VX Limiter suite: Peak, RMS, Excursion and multi-band limiting for passive 2-way systems
VX Limiter suite: Peak, RMS, Excursion and multi-band limiting for passive 2-way systems
✓
Per-channel impedance selection: 2 or 4 Ohms
Per-channel impedance selection: 2 or 4 Ohms
✓
25V, 70V and 100V constant voltage lines for distributed audio installations
25V, 70V and 100V constant voltage lines for distributed audio installations
✓
Remote Ethernet control via SE System Engineer; front panel for local configuration
Remote Ethernet control via SE System Engineer; front panel for local configuration
✓
Overlay grouping for Mutes, Gains, Delays and EQ across multiple amplifiers
Overlay grouping for Mutes, Gains, Delays and EQ across multiple amplifiers
Note
The 44 M20 supports 2 and 4 Ohm loads only – 8 Ohm operation is not available on this model. For 8 Ohm capability, see the 44 M6 or 44 M10 variants.
Specifications
| Channels | 4 |
| Power per Channel | 3,000W @ 4 Ohms |
| Bridged Power | Up to 10,000W |
| Impedance Options | 2 or 4 Ohms per channel (no 8 Ohm) |
| Constant Voltage | 25V, 70V, 100V |
| DSP Sample Rate | 96kHz |
| Network Audio | Dante |
| Control | Ethernet (SE System Engineer) + front panel |
| Form Factor | 2U rack mount |
| SKU | ZR1260 Dante |
