Elumen8 40m Socapex 19-Pin Male - Female Titanex 2.5mm Cable

SKU: CABL463C
Elumen8 40m Socapex 19-Pin Male - Female Titanex 2.5mm Cable
Elumen8 40m Socapex 19-Pin Male - Female Titanex 2.5mm Cable
Click to enlarge

    £725.00 inc VAT
    £604.17 ex VAT

    13 in stock

    Order in 7h 9m 16s for FREE delivery by Tuesday
    Click & collect available Monday ›
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    Bulk discounts available
    Quantity Unit price You save
    10–24 £688.75 5%
    25–39 £652.50 10%
    40+ £616.25 15%
    2 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    The Elumen8 40m Socapex 19-Pin Male to Female Titanex 2.5mm cable is a touring-grade multicore power cable carrying six dimmer circuits in a single run. Built in Britain using Titanex H07RN-F 2.5mm 18-core cable with Elumen8 Showsafe 19-pin connectors, it is the standard between dimmer racks and lighting bars on touring rigs, theatre flys and outdoor events. Amphenol Socapex SL419 compatible, IP67 when mated.

    LENGTH
    40m
    Single run

    CORE
    18 x 2.5mm
    Titanex H07RN-F

    CONNECTOR
    19-pin
    Showsafe M-F

    RATING
    IP67
    When mated

    Made in Britain

    Manufactured in the UK using Titanex H07RN-F 2.5mm 18-core cable, terminated with Elumen8 Showsafe 19-pin connectors. Amphenol Socapex SL419 compatible with FMLB (first make, last break) earth contacts and multipoint gold plated contacts.

    Features
    ✓40m run, 19-pin male to female
    ✓Titanex H07RN-F 2.5mm 18-core cable
    ✓Elumen8 Showsafe 19-pin connectors
    ✓Amphenol Socapex SL419 compatible
    ✓FMLB (first make, last break) earth contacts
    ✓Multipoint gold plated contacts
    ✓IP67 when mated
    ✓Oil resistant and flame retardant (IEC/EN 60332-1-2)
    ✓Crosslinked elastomer insulation, bare copper conductors
    ✓Operating temperature -25C to 55C

    Specifications
    Length 40m
    Cable Titanex H07RN-F 18 x 2.5mm
    Connectors Showsafe 19-pin male to female
    Compatibility Amphenol Socapex SL419
    IP rating IP67 when mated
    Operating temperature -25C to 55C
    Max conductor temp in service 90C
    Standards IEC/EN 60332-1-2 (flame retardant)
    Made in Britain

    More Information

    • Made in Britain
    • Length: 40m
    • Titanex H07-RNF 2.5mm 18 core cable
    • Elumen8 Showsafe 19-Pin connectors
    • Clear heatshrink suitable for identification or asset label
    • Oil resistant and flame retardant according to IEC/EN 60332-1-2 standard
    • Chemical resistant cross-linked elastomer insulation
    • Bare copper conductors
    • Operating temperature range: -25 to 55°C
    • Maximum conductor temperature in service: 90°C
    • Amphenol Socapex SL419 compatible
    • IP67 ingress protection when mated
    • FMLB (first make, last break) earth contacts
    • Multi-point gold plated contacts
    • Colour coding rings can be added at point of manufacture, contact our sales team for information
