Cloud 46-80T 4-Zone Mixer Amp 6-Line/2-Mic/ RS232 4x80W 100V 2U

SKU: 46-80TEK
Cloud 46-80T 4-Zone Mixer Amp 6-Line/2-Mic/ RS232 4x80W 100V 2U
Cloud 46-80T 4-Zone Mixer Amp 6-Line/2-Mic/ RS232 4x80W 100V 2U
Click to enlarge

    £1,224.00 inc VAT
    £1,020.00 ex VAT

    6 in stock (more available subject to additional lead time)

    Order in 17h 1m 31s for FREE delivery by Tuesday
    Click & collect available Monday ›
    VisaMastercardAmerican ExpressApple PayGoogle PayPayPalPayPal Credit
    1 Year Manufacturer Warranty Included
    About Stage Supply
    Chat to us on WhatsApp

    About this Product

    The Cloud 46-80T is a 4-zone mixer amplifier with integrated 100V transformer, delivering 4×80W on 100V line for distributed speaker systems. Six line and two mic inputs with RS232 control suit installations in hotels, retail, leisure centres, and licensed premises where multiple audio zones are needed.

    Zones
    4
    Power
    4×80W
    100V line
    Inputs
    6 Line +
    2 Mic
    4-Zone Commercial Audio

    The 46 series are Cloud’s established 4-zone mixer amplifiers, combining 6-line and 2-mic inputs with RS232 control. The -T suffix models include an integrated 100V transformer; standard models output 4Ω. The 46-120 MK2 is the updated version of the popular 46-120.

    Features
    ✓4 independently switchable amplified output zones
    ✓6-line and 2-mic inputs with individual level controls
    ✓RS232 serial control for integration with building systems
    ✓Priority input muting across all zones
    ✓Bass and treble tone controls
    ✓Signal and clip LED indicators per zone
    ✓2U 19″ rack format
    ✓Optional RS232/web/paging card (CDI-46) for extended control
    Specifications
    Output Power 4×80W
    Output 100V line
    Zones 4
    Inputs 6× line, 2× mic
    Control RS232
    Format 2U 19″ rack

    More Information

    • Eight input (6 x line, 2 x mic) mixing amplifier for four zones
    • 4 x 80 W power output, 70/100 V-line version also available (46-80T)
    • CXL-80T 70/100 V-line transformers may be retrofitted per-channel to 46-80
    • Slave mode: power amplifier stages may be paralleled in various configurations and fed from a single programme source
    • Peak limiter to protect power amplifier stages and loudspeakers
    • Utility/Loop output with independent mic/music mix and user-definable music source
    • Balanced, line level aux outputs (pre-power stage) from Zones 1 and 2
    • Four balanced and two unbalanced stereo line inputs with individual gain trim controls
    • Two balanced mic inputs; 15 V phantom power selectable on either or both
    • Zone 1 Facility Port for connection of optional remote input plates: LM-2 mic/line input + music controls, BT-1 Bluetooth input, L-1 line input, M-1 mic input
    • Music Mute control input (N/O or N/C) for emergency alarm system
    • Compatible with standard Cloud remote control panels: RL Series (music level) and RSL Series (music level and source selection), per-zone
    • RS-232 port for serial control of per-Zone MIC 1 muting, music level and source plus global unit standby, Music Mute and MIC 2 muting
    • User–selectable Automatic Power Down for maximum energy efficiency
    • Convection-cooled (no fan): silent in operation
